China White Black Color Electric Round Type Pe Material Circle Nail Concrete Cable Clips

China White Black Color Electric Round Type Pe Material Circle Nail Concrete Cable Clips

Place of Origin:

ANHUI CHINA

Brand Name:

YUSHUN

Model Number:

YS

Contact Us

Request A Quote
Product Details
Name:
Plastic Cable Clips
Material:
Plastic
Shape:
Round
Application:
Home, Office, Workshop
Feature:
Easy To Use
Supplier:
AnHui Yushun Co., Ltd
Payment & Shipping Terms
Minimum Order Quantity
negotiate
Price
negotiate
Packaging Details
100pac in one bag
Delivery Time
15-20days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram, MoneyGram
Supply Ability
30000bags pre day
Product Description

Cable clip is a plastic product. PE material injection molding, high elasticity, impact resistance, never break. Product series for pin type, steel nails directly attached to the online card, can save a lot of time, reduce the construction cost.



As for the size selection: Circle cable clip production specifications from 3.5 mm, 4 mm, 5 mm, 6 mm, 7 mm, 8 mm, 9 mm and 10 mm, 12 mm, 14 mm, 16 mm, 18 mm, 20 mm and 22 mm, 25 mm, 30 mm, and 32 mm, 35 mm, 40 mm, 50 mm. Square type steel nail cable clip specifications from 4mm to 14mm, hook type steel nail card specifications are 15mm,22mm,28mm.



As for the color selection: The most commonly used and popular color is white and black. In addition, we have many colors for you to choose from, such as white, red, yellow, blue, etc. We also support custom colors.



ITEM.NO. Height(mm) Diameter Nail(mm) Packing
H1(mm) R(mm)
4mm 5.2 3.8 4 1.7*14 100PCS
5mm 5.8 4.8 5 1.8*17
6mm 6.2 5.5 6 1.8*17
7mm 7 6.5 7 1.8*17
8mm 7.9 7.5 8 1.7*18
9mm 8.3 8.5 9 1.8*17
10mm 8.3 9.5 10 2.0*20
12mm 8.3 11.5 12 2.0*20
14mm 8.5 13.2 14 2.0*20





China White Black Color Electric Round Type Pe Material Circle Nail Concrete Cable Clips 0China White Black Color Electric Round Type Pe Material Circle Nail Concrete Cable Clips 1

China White Black Color Electric Round Type Pe Material Circle Nail Concrete Cable Clips 2China White Black Color Electric Round Type Pe Material Circle Nail Concrete Cable Clips 3





Details:

China White Black Color Electric Round Type Pe Material Circle Nail Concrete Cable Clips 4

Marked with Clear Size
The cable clips are marked with clear internal width, which's more convenient for your projects

China White Black Color Electric Round Type Pe Material Circle Nail Concrete Cable Clips 5

With Fixed Point
The point is helpful to hold the wire or the pipe firmly.

China White Black Color Electric Round Type Pe Material Circle Nail Concrete Cable Clips 6



Strengthened Nails
The head and the support body of the nails are solid.



Using occasions

China White Black Color Electric Round Type Pe Material Circle Nail Concrete Cable Clips 7

China White Black Color Electric Round Type Pe Material Circle Nail Concrete Cable Clips 8

Use of cable clip,can make the messy lines become orderly, as the use of holding line, can be convenient to hold two or more objects together, strong and firm!It will make the line cleaner and more tidy!

General indoor wiring fixed wire, some of the larger line card used for fixing cable pipes, water pipes, etc.It is widely used in Christmas gift factory, electronic factory, wire processing factory, wire and cable, toy factory, festival, stationery department store, fresh supermarket, residential daily use, electrical appliances, connectors and other items.





Mini Size and Medium Size Clips
The clips with a size lower than 8mm are generally suitable for the thin cable,such as the fiber optical cable, the USB cable, the network cable, the TV line and the power line.
The clips with a size between 9mm to 14mm are generally for the air conditional cable, the VGA line and so on.

China White Black Color Electric Round Type Pe Material Circle Nail Concrete Cable Clips 9

Large Size Clips or PVC Pipe Clamps
The clips with a size larger than 16mm are generally suitable for the pipes, such as the 3/8 inch pipe, 1/2 inch pipe, and3/4 inch, etc..

China White Black Color Electric Round Type Pe Material Circle Nail Concrete Cable Clips 10

Installation Notes:
1.Installation on sheetrock or concrete walls is not recommended.
2.Place every 12-18" or closer to support the weight of the cable.
3.Place the wire and use needle nose pliers to hold it into place.
4.Hammer the mounting nail into a mounting surface.



Company Profile

China White Black Color Electric Round Type Pe Material Circle Nail Concrete Cable Clips 11China White Black Color Electric Round Type Pe Material Circle Nail Concrete Cable Clips 12
      Anhui Yushun Plastic Co., LTD., is one of the largest professional manufacturing enterprises of building materials in China.
      As a professional manufacturer of ceramic tile spacer, wall plug, tile leveling system and nylon cable tie, cable clip and other building materials hardware company. We have senior designers who can design and customize products to meet your requirements, professional quality control personnel who can strictly control the quality of each product and rich work experience can supply you more professional service.As a result of strong production capacity of two tons every day ,our high quality products and outstanding customer service,so we are winning more and more clients’ trust during the global sales, reaching The United States, Germany, Russia and Southeast Asia. Furthermore,I would like to emphasize that we are not a simple trading company. We are a trading company with our own factories, and we work in the mode of producing and selling products by ourselves. Therefore, you do not need to worry about the supply and demand of products, we have a stable supply chain.
Finally, we have many designs of packing and molds upon request. If you are interested in any of our products or we'd like to discuss a custom order. Please feel free to contact us, we are looking forward to forming successful business relationships around the world in the near future.





FAQ

Q1: Are you factory ?

A: We are factory.We not only produce customized cable clips, but also produce the other plastic products.



Q2: How long is your delivery time?

A: It is according to the product you need and quantity ,usually in 30 days .



Q3: Can you provide samples ?

A: Yes, we can supply samples if we have stock.But if its customized , you need pay us mould fee, sample cost .



Q4: What drawings format you need for production?

A: 2D: PDF, CAD, JPG etc.

3D: STP, IGS, STL, SAT,PRT,IPT etc.



Q5:Can you produce according to the samples?

A: Yes, we can produce according to your samples .
